Spring Check Valve PN 10/16
- The valve is used as a one-way flow valve to prevent backflow on industrial and construction installations
- Utilized in all water line systems and all non-corrosive liquids with a maximum temperature of 80°c
- Body made of ductile iron (GJS400) EN 1563 (DIN 1693) even in PN 10 valves.
- The wedge of ductile iron (GJS400) encapsulated with vulcanized EPDM resistant against friction and hammer effects
- Flange face to face dimension according to EN 558 (DIN 3202-P1-F6)
- Flange drilled to EN 1092-P2 (DIN 2501)
- Opening range proportional to water pressure
- Minimum opening differential pressure 0.1 bar
- Minimum closing differential pressure 0.5 bar
- Suitable for installing in the vertical position
- Fast closing of the wedge with spring pressure and preventing the return of water (suitable) in pumping stations where the return of water causes impact and is harmful to the system.
- When installing the valve, pay great attention to the direction of the arrow on the body
